• HDCP Authorized — Press the navigation buttons to enable or disable the HDCP
Authorized feature for each digital input. This feature determines if a digital input will
report as an HDCP authorized sink to a source.
NOTES:
The HDCP Authorized feature does not apply to input 2 of an HC 404 or
•
HC 403 system, as that is an analog input.
The HDCP Authorized feature also does not apply for input 2 of an HC 402 or
•
HC 402 EU/MK system. The HCT 101 transmitters do not support configuration
of HDCP authorization.
Enable HDCP Authorized for source devices that require encryption. If HDCP Authorized
is disabled for sources that require encryption (for example, a Blu-ray
output is muted or a warning message is displayed. By default this feature is enabled.
Some source devices may encrypt their output even if the source material does not
require HDCP encryption, preventing content from being displayed on a non-HDCP
compliant display. Disable the HDCP Authorized feature to allow the output to remain
unencrypted.
• EDID — Press the navigation buttons to select an EDID for the active input. Select a
discrete EDID from a list of factory-supplied EDID or select Match Output to use
the output resolution and refresh rate (see
available resolutions and refresh rates).
NOTE: The EDID feature does not apply for input 2 of an HC 402 or
HC 402 EU/MK system. The HCT 101 transmitters do not support EDID
configuration. The HCT 101 input EDID is fixed at 1080p, 60 Hz
Output submenu
Quick Setup Quick Setup
Picture Controls Picture Controls
Input Input
Output
Output
Audio Audio
Advanced Advanced
Communications Communications
Device Info Device Info
Figure 29. Output Submenu
The Output submenu configures the output resolution, refresh rate, HDMI format, and
HDCP notification.
Resolution
Resolution
1080p @60Hz
HDMI Format
AUTO
HDCP Notification
On
player), the
™
on page 48 for a full list of
