Extron electronics HC 400 Series User Manual page 41

HCT 103
Rear Panel
2 3 4
POWER
12V
AUDIO
0.5A MAX
RGB HDMI HDMI
INPUTS
R • Receiver front panel
HCR 102
Front Panel
HCT 103
Rear Panel
2 3 4
POWER
12V
AUDIO
0.5A MAX
RGB HDMI HDMI
INPUTS
To
AC
Ridged
power
– Return
+12 VDC input
Smooth
18 watt
NOTE:
Transmitter Power Input
• Connect to optional
12 VDC, 1.5 A power supply.
You have two options for powering the system:
NOTE: These examples show the HCT 103, but the connections are identical for the
other HCT transmitters.
Connect the included 12 VDC, 4.2 A power supply (Extron PS 1242) at the receiver.
•
AV, Communication, Power
SIG LINK REMOTE
HCT 103
CONTACT TALLY
OUT 1 2 3 G 1 2 3 +V
Remote Power:
50 watt Receiver Power Input
• Connect an included
LED ( ) blinks 12 VDC, 4.2 A power
during boot-up and supply to the receiver
remains lit when the only. The receiver
unit is powered and supplies power to
operational. the transmitter.
Figure 21. Connecting a 50 watt Power Supply for Remote Power
NOTE: The receiver can provide power remotely to the transmitter using a
50 watt power supply. Remote power mode requires at least 2.5 A. The
transmitter can receive power from but cannot provide power to the receiver.
The remote power feature is enabled by default but can be disabled by using
a control in the PCS software.
Alternatively, you can connect an optional 12 VDC, 1.5 A power supply (such as
•
the Extron PS 1215 C) at the transmitter, and connect an optional 12 VDC, 2 A power
supply (such as the Extron PS 1220) at the receiver.
AV and Communication Only
SIG LINK REMOTE
HCT 103
CONTACT TALLY
OUT 1 2 3 G 1 2 3 +V
External
Power Supply
(12 VDC, 1.5 A max.,
Extron P/N 28-327-57LF)
Check the polarity of
each power supply before
connecting it to a unit.
Figure 22. Connecting Each Unit to an External Power Supply
Connect the external power supply or supplies to a 100 to 240 VAC power source.
INPUTS SIG LINK OUTPUTS
POWER
12V
1 TP
2.0A MAX
HDMI HDMI/CEC
IN
To AC power
Ridged
– Return
+12 VDC input
Smooth
INPUTS SIG LINK OUTPUTS
POWER
12V
1 TP
2.0A MAX
HDMI IN HDMI/CEC
To
AC
Ridged
power
– Return
+12 VDC input
Smooth
24 watt Receiver Power Input
• Connect to optional • Receiver front panel LED (
12 VDC, 2 A during boot-up and remains lit when
power supply. the unit is powered and operational.
HC 400 Series • Hardware Features and Installation
HCR 102
Rear Panel
COM IR DIGITAL I/O
HCR 102
AUDIO
L R
LAN
Tx Rx G S G 1 2 G 3 4 G
Ground all devices.
External
Power Supply
(12 VDC, 4.2 A max.,
Extron P/N 28-394-07LF )
HCR 102
Rear Panel
COM IR DIGITAL I/O
HCR 102
AUDIO
L R
LAN
Tx Rx G S G 1 2 G 3 4 G
Ground all devices.
External
Power Supply
(12 VDC, 2 A max.,
Extron P/N 28-416-57LF)
R
) blinks
HCR 102
Front Panel
33
