Planning the Suspension System

Optional Mid Line Controls may be used for partial house brooding. (See Figure 1.)
5
2
Figure 1. Component location diagram for systems up to 400 feet [122 m]. (Top View).
Systems with line lengths over 400' [122 m] should be split in the center, as shown in Figure 2. This will reduce
auger running time and eliminate the need for Mid-Line Controls for partial house brooding.
10'[3m] Minimum
to Power Unit
3
Item Description
1 Brood Curtain
2 Control Tube
3 End Control and Power Unit
Figure 2. Component location diagram for systems over 400 feet [122 m]. (Top View).
MF2505A
10'[3m] Minimum
3
Item Description
1 Brood Curtain
2 Feed Bin
3 Mid Line Control
10'[3m] Minimum
1
Item Description
4 End Control and Power Unit
5 Feeder Hopper
10'[3m] Minimum
to Power Unit
1
4
5
Item Description
4 Feeder Hopper
5 Feed Bin
4
3
