Configuring the local display

12.6.1

Factory setting of local display for level measurements

Parameter Factory setting for devices with 1 current
output
Format display 1 value, large format
Value 1 display Level linearized
Value 2 display Distance
Value 3 display Current output 1
Value 4 display None
The local display can be customized in the Transducer Block DISPLAY (TRDDISP).
12.7

Configuration management

After commissioning, you can save the current device configuration, copy it to another
measuring point or restore the previous device configuration. You can do so using the
Configuration management parameter and its options.
Path in the menu
Setup → Extended setup → Data backup → Configuration management
Block operation
Block: DISPLAY (TRDDISP)
Parameter: Configuration management (configuration_management)
Functions of the parameter options
Options Description
33097: Backup A backup copy of the current device configuration in the HistoROM is saved to the
display module of the device. The backup copy includes the transmitter data of the
device.
33057: Restore The last backup copy of the device configuration is copied from the display module
to the HistoROM of the device. The backup copy includes the transmitter data of
the device.
33838: Duplicate The transmitter configuration from another device is duplicated to the device using
the display module.
Levelflex FMP56, FMP57 FOUNDATION Fieldbus
Parameter Action
Signal quality Displays the signal quality of the analyzed level
(signal_quality) echo.
Confirm distance Compare the distance displayed with the actual
(confirm_distance) value to start recording an interference echo
map.
Options:
• 179: Record map manually
• 32847: Delete mapping curve
• 32859: Distance Ok
• 32860: Distance too large
• 32861: Distance too small
• 32862: Distance unknown
• 33100: Tank empty
Factory setting for devices with 2 current
outputs
1 value, large format
Level linearized
Distance
Current output 1
Current output 2
