Configuring The Local Display; Invert Output Signal (0470) - Endress+Hauser Proline Prosonic Flow W 400 Operating Instructions Manual

Commissioning
Parameter
Assign flow direction check
Assign status
Switch-on value
Switch-off value
Switch-on delay
Switch-off delay
Failure mode
Invert output signal
* Visibility depends on order options or device settings
100
Prerequisite
• The Switch option is
selected in the Operating
mode parameter.
• The Flow direction check
option is selected in the
Switch output function
parameter.
• The Switch option is
selected in Operating mode
parameter.
• The Status option is
selected in Switch output
function parameter.
• The Switch option is
selected in the Operating
mode parameter.
• The Limit option is selected
in the Switch output
function parameter.
• The Switch option is
selected in the Operating
mode parameter.
• The Limit option is selected
in the Switch output
function parameter.
• The Switch option is
selected in the Operating
mode parameter.
• The Limit option is selected
in the Switch output
function parameter.
• The Switch option is
selected in the Operating
mode parameter.
• The Limit option is selected
in the Switch output
function parameter.
–
–
10.4.8

Configuring the local display

The Display wizard guides you systematically through all the parameters that can
configured for configuring the local display.
Navigation
"Setup" menu → Display
‣
Display
Format display
Description
Select process variable for flow
direction monitoring.
Select the device function for
which to report the status. If
the function is triggered, the
output is closed and conductive
(standard configuration).
Enter limit value for switch-on
point (process variable >
switch-on value = closed,
conductive).
Enter limit value for switch-off
point (process variable <
switch-off value = open,
nonconductive).
Enter a delay before the output
is switched on.
Enter a delay before the output
is switched off.
Select output behavior in the
event of a device alarm.
Invert the output signal.
Proline Prosonic Flow W 400 HART
Selection / User Factory setting
entry
–
• Off –
• Low flow cut off
Signed floating-point Depends on country
number
Signed floating-point Depends on country
number
0.0 to 100.0 s –
0.0 to 100.0 s –
• Actual status –
• Open
• Closed
• No –
• Yes
→  101
