Levelflex FMP56, FMP57 FOUNDATION Fieldbus
Unit after linearization
Navigation
Prerequisite
Endress+Hauser
Meaning of the options
• None
The level is output in the level unit without being converted (linearized) beforehand.
• Linear
The output value (volume/weight) is proportional to the level L. This applies, for
example, to vertical cylindrical tanks and silos. The following parameters must also be
specified:
• Unit after linearization (→  153)
• Maximum value (→  155): maximum volume or weight
• Table
The relationship between the measured level L and the output value (volume/weight) is
defined by a linearization table consisting of up to 32 pairs of values "level - volume" or
"level - weight" respectively. The following parameters must also be specified:
• Unit after linearization (→  153)
• Table mode (→  156)
• For every point in the table: Level (→  157)
• For every point in the table: Customer value (→  158)
• Activate table (→  158)
• Pyramid bottom
The output value corresponds to the volume or weight in a silo with a pyramid bottom.
The following parameters must also be specified:
• Unit after linearization (→  153)
• Maximum value (→  155): maximum volume or weight
• Intermediate height (→  156): the height of the pyramid
• Conical bottom
The output value corresponds to the volume or weight in a tank with a conical bottom.
The following parameters must also be specified:
• Unit after linearization (→  153)
• Maximum value (→  155): maximum volume or weight
• Intermediate height (→  156): the height of the cone
• Angled bottom
The output value corresponds to the volume or weight in a silo with an angled bottom.
The following parameters must also be specified:
• Unit after linearization (→  153)
• Maximum value (→  155): maximum volume or weight
• Intermediate height (→  156): height of the angled bottom
• Horizontal cylinder
The output value corresponds to the volume or weight in a horizontal cylinder. The
following parameters must also be specified:
• Unit after linearization (→  153)
• Maximum value (→  155): maximum volume or weight
• Diameter (→  155)
• Sphere
The output value corresponds to the volume or weight in a spherical tank. The following
parameters must also be specified:
• Unit after linearization (→  153)
• Maximum value (→  155): maximum volume or weight
• Diameter (→  155)
 Setup → Advanced setup → Linearization → Unit lineariz.
Linearization type (→  152) ≠ None
