Levelflex FMP56, FMP57 FOUNDATION Fieldbus
User entry
Level linearized
Navigation
Description
Additional information
Maximum value
Navigation
Prerequisite
User entry
Diameter
Navigation
Prerequisite
User entry
Additional information
Endress+Hauser
Up to 32 alphanumerical characters (letters, numbers, special characters)
 Setup → Advanced setup → Linearization → Level linearized
Displays linearized level.
The unit is defined by the Unit after linearization parameter →  153.
 Setup → Advanced setup → Linearization → Maximum value
Linearization type (→  152) has one of the following values:
• Linear
• Pyramid bottom
• Conical bottom
• Angled bottom
• Horizontal cylinder
• Sphere
–50 000.0 to 50 000.0 %
 Setup → Advanced setup → Linearization → Diameter
Linearization type (→  152) has one of the following values:
• Horizontal cylinder
• Sphere
0 to 9 999.999 m
The unit is defined in the Distance unit parameter (→  133).
Operating menu


155
