Levelflex FMP56, FMP57 FOUNDATION Fieldbus
Name Label
bin_type Bin type
confirm_distance Confirm distance
filtered_dist_val Distance
map_end_x Present mapping
mapping_end_point Mapping end point
record_map Record map
signal_quality Signal quality
empty_calibration Empty calibration
full_calibration Full calibration
distance_unit Distance unit
level_unit Level unit
output_unit_after_lineariza Unit after linearization
tion
level_linearized Level linearized
present_probe_length Present probe length
level Level
decimal_places_menu_ro Decimal places
Endress+Hauser
Channel Measured value
145 Interface distance
172 Calculated DC value
211 Terminal voltage
212 Sensor debug
32785 Absolute EOP amplitude
32786 Absolute echo amplitude
32787 Absolute interface amplitude
32856 Distance
32885 Elektronic temperature
32938 Interface linearized
32949 Level linearized
33044 Relative echo amplitude
33045 Relative interface amplitude
33070 Noise of signal
33107 Upper interface thickness
9.6

Index tables of Endress+Hauser parameters

The following tables list the manufacturer-specific device parameters for the Resource
Blocks. For the FOUNDATION Fieldbus parameters, see the document BA062S "Guidline -
FOUNDATION Fieldbus Function Blocks", which can be downloaded from
www.endress.com.
9.6.1

Setup Transducer Block

Index
54
82
76
84
83
86
81
56
57
51
58
62
64
87
60
93
Integration into a FOUNDATION Fieldbus network
Data type Size Storage
(Bytes) Class
ENUM16 2 Static
ENUM16 2 Static
FLOAT 4 Dynamic
FLOAT 4 Dynamic
FLOAT 4 Static
ENUM16 2 Static
ENUM16 2 Dynamic
FLOAT 4 Static
FLOAT 4 Static
ENUM16 2 Static
ENUM16 2 Static
ENUM16 2 Static
FLOAT 4 Dynamic
FLOAT 4 Dynamic
FLOAT 4 Dynamic
ENUM16 2 Static
Write MODE_BL Description
access K
x OOS →  133
x OOS →  136
→  135
→  137
x AUTO →  137
x OOS →  138
→  136
x OOS →  133
x OOS →  134
x OOS →  133
x OOS →  147
→  153
→  155
x AUTO →  162
→  134
x AUTO →  173
