Levelflex FMP56, FMP57 FOUNDATION Fieldbus
Status
Navigation
Description
Value
Navigation
Description
Units index
Navigation
Description
*
Visibility depends on order options or device settings
Endress+Hauser
• Terminal voltage
*
• Thickness upper layer
*
• Calculated DC value
• Analog output adv. diagnostics 2
• Analog output adv. diagnostics 1
 Diagnostics → Analog inputs → Analog input 1 to 7 → Status
Indicates the status of the output of the AI block according to the FOUNDATION Fieldbus
specification.
 Diagnostics → Analog inputs → Analog input 1 to 7 → Value
Indicates the output value of the AI block.
 Diagnostics → Analog inputs → Analog input 1 to 7 → Units index
Indicates the unit of the output value.
Operating menu
191
