Advanced Setup" Submenu - Endress+Hauser Levelflex FMP56 Operating Instructions Manual

Operating menu
Locking status
Navigation
Description
User interface
Additional information
Access status tooling
Navigation
Description
Additional information
Access status display
Navigation
Prerequisite
142
17.3.3

"Advanced setup" submenu

Navigation 
 Setup → Advanced setup → Locking status
Indicates the write protection with the highest priority that is currently active.
• Hardware locked
• Temporarily locked
Meaning and priorities of the types of write protection
• Hardware locked (priority 1)
The DIP switch for hardware locking is activated on the main electronics module. This
locks write access to the parameters.
• SIL locked (priority 2)
The SIL mode is activated. Writing access to the relevant parameters is denied.
• WHG locked (priority 3)
The WHG mode is activated. Writing access to the relevant parameters is denied.
• Temporarily locked (priority 4)
Write access to the parameters is temporarily locked on account of internal processes in
progress in the device (e.g. data upload/download, reset etc.). The parameters can be
modified as soon as the processes are complete.
On the display module, the -symbol appears in front of parameters that cannot be
modified since they are write-protected.
 Setup → Advanced setup → Access stat.tool
Shows the access authorization to the parameters via the operating tool.
The access authorization can be changed via the Enter access code parameter
(→  143).
If additional write protection is active, this restricts the current access authorization
even further. The write protection status can be viewed via the Locking status
parameter (→  142).
 Setup → Advanced setup → Access stat.disp
The device has a local display.
Levelflex FMP56, FMP57 FOUNDATION Fieldbus
Setup → Advanced setup
Endress+Hauser
