Teldat 5Ge-Rail Installation Manual page 33

Teldat S.A.
Connector
SIM Slots
Antenna
A.4.3.1 Antenna connectors and bands
Bands used for each antenna connector
Transmission
Connector
3G /
WCDMA
4G /
LTE
5G-NR /
FR1
Reception
Connector
3G /
WCDMA
4G /
LTE
5G-NR /
FR1
Teldat 5Ge-Rail Router
• 2 layers LTE + FDD (20MHz BW, 256QAM, SISO): ~320Mbps
• LTE:
• DL Cat 20: up to 20 layers (Up to 2Gbps)
• UL Cat 18: 2CC intra-band contiguous and inter-band, 256QAM (Up to 210
Mbps)
• Supported BW: 1.4–20 MHz, per 3GPP specs for supported bands
• HSPA+ Cat 24/6: 42Mbps/5.76Mbps
Two (LTE) or four (5G) QMA connectors.
2 Mini-SIM (2FF) ISO/IEC 7810:2003, ID-000 (1.8V / 3V)
The antennas are supplied separately from the device.
A B
B1, B2, B4, B5, B6, B8,
B9, B19
B1, B2, B3, B4, B5, B7, B5, B20, B42, B43,
B8, B12, B13, B14, B48, B71
B17,B18, B19, B20,
B25, B26, B28, B30,
B34, B38, B39, B40,
B41, B66, B71
n1, n2, n3, n5, n7, n8, n5, n48, n77, n78, n79
n12, n20, n28, n38,
n40, n41, n66, n71
A B
B1, B2, B4, B5, B6, B8, B1, B2, B4, B5, B6, B8,
B9, B19 B9, B19
B1, B2, B3, B4, B5, B7, B1, B2, B3, B4, B5, B7,
B8, B12, B13, B14, B8, B12, B13, B14,
B17, B18, B19, B20, B17, B18, B19, B20,
B25, B26, B28, B29, B25, B26, B28, B29,
B30, B32, B34, B38, B30, B32, B34, B38,
B39, B40, B41, B42, B39, B40, B41, B42,
B43, B46, B48, B66, B43, B46, B48, B66,
B71 B71
n1, n2, n3, n5, n7, n8, n1, n2, n3, n5, n7, n8,
n12, n20, n25, n28, n12, n20, n25, n28,
n38, n40, n41, n48, n38, n40, n41, n48,
n66, n71, n77, n78, n66, n71, n77, n78,
n79 n79
C D
B1, B2, B3, B4, B7,
B41, B66
n1, n2, n3, n7, n25,
n41, n66, n77, n78,
n79
C D
B1, B2, B3, B4, B7, B1, B2, B3, B4, B7,
B25, B30, B32, B34, B25, B30, B32, B34,
B38, B39, B40, B41, B38, B39, B40, B41,
B42, B43, B46, B48, B42, B43, B46, B48,
B66 B66
n1, n2, n3, n7, n25, n1, n2, n3, n7, n25,
n38, n40, n41, n48, n38, n40, n41, n48,
n66, n77, n78, n79 n66, n77, n78, n79
Technical Information
29
