Technical Information
A.4.8 Electrical specifications
Nominal Supply Voltage
Nominal Power Consumption
Inrush Current Characteristics
DC Power Supply fluctuation
range
Interruptions on Power Supply
voltage Class
Supply Change-over Class
Earth Protection Reference
Power over Ethernet
To ensure safe operation, Teldat 5Ge-Rail devices have a protective earth connection. The minimum cross-section
of the earth lead should be 2.5 mm
as possible.
A.4.9 Mechanical specifications
Equipment dimensions without
cable
(W x L x H)
Weight
Material
Noise
Ingress Protection Rating
LEDs
32
Un = 24 V – 110 V d.c.
12 W typical, 20W maximum at full load, 55 W maximum for a short time in special
cases.
0.1 A 2s [I2t].
14.4 V – 154 V d.c.
S2 (10 ms)
Not supported
Zero Volts or Ground
According to 802.3at (PoE+) on LAN-1 (> 5 °C only)
2
. The distance between the device and the earth connection should be as short
ca. 212 x 212 x 40 mm plus 30 mm mounting kit (2 x 15 mm).
Approx. 3000 g.
Paint-coated galvanized iron sheet.
0 dB (fanless).
IP40 (EN 60529) Solid particle protection > 1 mm.
5 (Power, LAN1, LAN2, W, SIM).
