3 Components and Power Supply
GND

3.2 Mounting Options

Note
The device should be handled and installed by qualified service personnel, otherwise it could be dam-
aged or malfunction.

3.2.1 Assembly: Recommendations

Thanks to brackets in the housing, the Teldat 5Ge-Rail can be mounted on the wall or ceiling.
Wall-/Ceiling mounting
To install the device on the wall/ceiling, the mounting brackets may be readily attached to the housing. They are
screwed to the wall/ceiling using six screws.
Warning
Before drilling, make sure that there are no building installations nearby. If gas, electricity, water or
waste water lines are damaged, you may endanger your life or damage property.
• Screw the mount to the wall with the 6 screws. This will ensure the device is securely mounted.
• Make sure the device connections are accessible.

3.2.2 Outline drawing

The following outline drawing provides installation instructions:
8
Ground Protection Screw.
Refer to Electrical specifications
nection.
on page 32 for more information on Power Con-
