INTELLI-TRACK™ SPS SYSTEM
Re-install the Roller Access Splice
After all Sliding Wall Panels have been attached to the Top Track, re-install the Roller Access Splice that was removed
in.
Adjust Roller Spacing for the Parking Area
1. Move the Panel nearest to the parking area to the parking area's double Track entrance. Working with the Roller
Assembly that first enters the parking area, loosen the Lateral Adjustment Locking Nut on this end only.
Carefully move the Wall Panel into the parking area until it comes to rest. Adjust the position of the Intelli-Track
Roller Assemblies laterally until both Pendant Bolts are centered in the Track slots (important step for smooth
operation), and retighten the Lateral Adjustment Locking Nut.
2. Repeat step 1 for all of the Sliding Wall Panels.
