INTELLI-TRACK™ SPS SYSTEM
INTRODUCTION
INTELLI-TRACK

IMPORTANT NOTES:

1) The CRL Intelli-Track
download, free of charge, our "SPS Structural Engineering Design Guide" for use by the architectural/engineering
design group on this project.
2) Fasten Track to the overhead support structure with 3/8" (9.5) Hex Head type fasteners made from one of the
following materials: A307 galvanized or A316 stainless steel. Always use Lock Washers.
3) All glass should be fully tempered with polished edges. Laminated glass should not be used with CRL Wedge-Lock
Rails. However, laminated glass can be used for fully framed wall Panel installations.
4) Track is pre-drilled to allow for mounting to optional suspension brackets or directly to concrete, metal or wood.
Please consult with CRL Technical Sales. Fasteners to attach Track or brackets to structure are not provided by CRL.
5) The circular table/bench saw must be capable of cutting 3/8" (9.5) thick aluminum sections. The diameter of the
aluminum cutting blade must accommodate an extrusion profile with the following dimensions: 4-7/8" (123.8)
wide x 3-9/16" (90.5) tall. Miter cutting capability will not be required in most cases, as CRL provides prefabricated
corners and intersections.

Tools Required

• 7/8" Open-End Wrench (Two)
• 9/16" Socket Hex
• Ratchet Wrench with 4" Extension
• 3/16" Hex Bit Socket or T-Handle Hex Tool
• 7/32" Hex Bit Socket or T-Handle Hex Tool
• 2 mm Hex Bit Socket or T-Handle Hex Tool
• Hammer with Smooth Face
• Saw Horses (Two)
The rapidly changing technology within the architectural aluminum products industry demands that C.R. Laurence/U.S. Aluminum reserve the right to
revise, discontinue, or change any product line, specification, or electronic media without prior written notice.
NOTE: Dimensions in parentheses ( ) are millimeters unless otherwise noted.
C.R. Laurence Co., Inc. • 2503 E. Vernon Ave., Los Angeles, CA 90058
SPS
™
Stacking Partition System has unique structural support requirements. Please request or
™
• CRL PLS2 Palm Laser Level or
Optional Conventional Level
• CRL Glass Cleaner
• Cordless Drill
• #1 Phillips Screwdriver
• Circular Table/Bench Saw with Aluminum
Cutting Blade
• 1.800.421.6144
