Install the Access Point Using KT-150173-01 Extension
Arm
4. Attach one end of the KT-150173-01 extension arm to the 1-axis tilt bracket using two hex-head M12
stainless-steel screws and two hex-head M12 stainless-steel nuts through the two large circular holes
on the KT-150173- 01 extension arm.
5. Attach the KT-150173-01 extension arm, that now has the access point mounted on the other end, to
a flat surface using four M6 size hex-head screws.
Use screw-in anchors with the four M6 hex-head screws when you mount the bracket on a wood
surface and use concrete anchors for concrete surface.

Install the Access Point Using KT-150173-01 Extension Arm

Before You Begin
Hardware required to install the access point on a wall using the KT-150173-01 extension arm:
•
KT-150173-01 extension arm
•
Four M6 screws
•
Four M6 hex-head screws
•
One access point
Procedure
1. Using the KT-150173-01 extension arm as a template, mark and drill four hole centers on a flat
surface.
The holes must be within the circular cuts in the end of the flange.
2. Attach one end of the KT-150173-01 extension arm to the access point using four M6 screws.
3. Attach the other end of the KT-150173-01 extension arm to the wall using four M6 hex-head screws.
Use screw-in anchors with the four M6 hex-head screws when you mount the bracket on a wood
surface and use concrete anchors for concrete surface.

Install the Access Point on a Pole

Before You Begin
The access point is used with the KT-147407-02 bracket parts and KT-150173-01 extension arm for pole
installation. The access point is mounted on a pole by attaching:
1. All three parts of the KT-147407-02 bracket.
2. The KT-150173-01 extension arm with all the KT-147407-02 bracket parts.
3. The pole bracket part of the KT-147407-02 bracket.
4. The KT-150173-01 extension arm with the pole part of the KT-147407-02 bracket.
The following hardware is required to install the AP560i access point on a pole:
•
Flat part of the KT-147407-02 bracket
•
Pole part of the KT-147407-02 bracket
•
1-axis tilt bracket
•
Six M6 screws
•
Two hex-head M12 stainless-steel screws
•
Two hex-heads M12 stainless-steel nuts
22 ExtremeWireless™ AP560h Access Point
