Alinx ZYNQ UltraScale+ AXU9EGB User Manual page 54

FMC_GBTCLK0_M2C_P
FMC_GBTCLK0_M2C_N
FMC_GBTCLK1_M2C_P
FMC_GBTCLK1_M2C_N
FMC_DP0_C2M_P
FMC_DP0_C2M_N
FMC_DP1_C2M_P
FMC_DP1_C2M_N
FMC_DP2_C2M_P
FMC_DP2_C2M_N
FMC_DP3_C2M_P
FMC_DP3_C2M_N
FMC_DP4_C2M_P
FMC_DP4_C2M_N
FMC_DP5_C2M_P
FMC_DP5_C2M_N
FMC_DP6_C2M_P
FMC_DP6_C2M_N
54 / 66
Number
130_CLK0_P
130_CLK0_N
129_CLK0_P
129_CLK0_N
130_TX0_P
130_TX0_N
130_TX1_P
130_TX1_N
130_TX2_P
130_TX2_N
130_TX3_P
130_TX3_N
129_TX0_P
129_TX0_N
129_TX1_P
129_TX1_N
129_TX2_P
129_TX2_N
AXU9EGB User Manual
FMC Transceiver Reference Clock 0
G27
Positive
FMC Transceiver Reference Clock 0
G28
Negative
FMC Transceiver Reference Clock 1
L27
Positive
FMC Transceiver Reference Clock 1
L28
Negative
FMC Transceiver Data Transmission 0
F29
Positive
FMC Transceiver Data Transmission 0
F30
Negative
FMC Transceiver Data Transmission 1
D29
Positive
FMC Transceiver Data Transmission 1
D30
Negative
FMC Transceiver Data Transmission 2
B29
Positive
FMC Transceiver Data Transmission 2
B30
Negative
FMC Transceiver Data Transmission 3
A31
Positive
FMC Transceiver Data Transmission 3
A32
Negative
FMC Transceiver Data Transmission 4
K29
Positive
FMC Transceiver Data Transmission 4
K30
Negative
FMC Transceiver Data Transmission 5
J31
Positive
FMC Transceiver Data Transmission 5
J32
Negative
FMC Transceiver Data Transmission 6
H29
Positive
FMC Transceiver Data Transmission 6
H30
Negative
