Hose System; Figure 3 Hose Diagram; Figure 4 Fast Connector - Endress+Hauser analytikjena multi N/C UVHS Operating Manual

multi N/C UVHS, multi N/C pharma UV
3.1.2

Hose system

Hose diagram
Water traps
11
Halogen trap
12
Flow monitoring
13
"internal" connection
14
"analyte" connection
29
"pump"
NDIR
30
connection
31
Condensate pump
16
Waste
18
Figure 3 Hose diagram
Connection method
The connection between the individual components is made with labeled hoses. The
numbers and letters circled in the hose diagram correspond to the labels on the hoses in
the analyzer.
20
19
17
1
15
Ultrapure water
Inside the device, most gas connections have been implemented via FAST connectors
(FAST – Fast, Safe, Tight). These connectors provide a tight transition between the
hoses and connections with different diameters. The soft sleeves prevent the risk of
glass breakage in comparison to rigid screw connections. There are different connector
versions.
Figure 4 FAST connector
So-called Fingertight screw connections are also used. These flangeless fittings consist
of a conical nipple and a banjo bolt. These hose connections seal purely by tightening
the plastic banjo bolt finger-tight.
8
4
Syringe pump
2
5
A
7
3
Water
traps
6
B
purge
needle valve
10
Sample
NPOC
needle valve
Function and design
23
21
22
17
