multi N/C UVHS, multi N/C pharma UV
10

Specifications

10.1 Technical data

General characteristics
Methods data
Process control
Gas supply
Electrical variables
Designation/type
Basic device dimensions (W x H x D)
Basic device mass
Digestion principle
Measuring methods
Temperature of the measuring medium
Sample feed
Sample volume
Particle handling capacity
Carbon detection principle
TC, TOC, NPOC, TIC measurement range
TC, TOC in solid measurement range
(with the HT 1300 solids module)
Control and analysis software
Software function scope
Option 1 Nitrogen
Option 2 Argon
Inlet pressure 400 to 600 kPa
Flow rate 15 l/h
Analyte gas flow 140 ml/min
NPOC purge 100 ml/min
flow
Voltage
Frequency
Fuses
multi N/C UVHS
multi N/C pharma UV
513 x 464 x 550 mm
30 kg
Wet chemical UV oxidation at 185 nm;
254 nm with Na S O as oxidant
2 2 8
TC, TIC, TOC (differential method), NPOC,
DOC
80 °C
Flow injection
50 to 20000 µl
In accordance with DIN EN 1484
NDIR (coupled with the VITA method)
0 to 10000 mg/l
0 to 500 mg
multiWin
Real-time graphics, status indication during
analysis, graphical display of the measured
results, result print-out
Data integrity and conformity with pharma-
ceutical guidelines 21 CFR Part 11 and Eu-
draLex Volume 4 Annex 11 in the pharma-
ceutical software.
≥5.0
≥4.6
100 to 240 V
50/60 Hz
2 T4 A H
Specifications
103
