multi N/C UVHS, multi N/C pharma UV
6.2

Adjustment and setting

6.2.1

General notes for adjusting the autosampler

6.2.2

Adjusting the AS vario autosampler

Maintenance interval
Quarterly
Every 6 months
Every 12 months
During adjustment, the canulas are adjusted to the sample tray for optimum immersion
in the sample vessels and/or wash cups.
An adjustment of the autosampler is necessary:
Before the first start
¡
¡ After each change of the sample tray
¡ During recommissioning after transport or storage
Adjustment of the AS 10e and AS 21hp autosamplers is described under Installation and
Commissioning.
See also
2 Installing and commissioning the sampler [} 42]
NOTICE
Risk of bending
The canula may bend during adjustment.
¡ Unscrew the screw connections on the canulas before adjustment.
} Start the software. Wait for the device to initialize.
} Open the window of the same name with the Instrument |Sampler Alignment menu
option.
} Select needle in the list field in the Please select position needing adjustment group.
ü The autosampler arm moves over the adjustment points on the sample tray.
Maintenance task
Check the TIC condensate container and the condensation
¡
coil for cracks and damage.
¡ Replace the water traps on the front and on the gas box.
¡ Clean the TIC condensate container and the condensation
coil (or earlier if necessary).
Maintenance and care
71
