Feeder Line Components; Power Unit Components; Power Unit Assembly Part Numbers - Chore-Time ATF Installation And Operator's Manual

Parts Listing

Feeder Line Components

Item Description
1*
2 ATF 10 ft. 2 hole tube
* ATF 10ft. 3 hole tube
* ATF 20ft. 3 hole tube
* ATF 20ft. 3 hole tube
** ATF 10ft. 5 hole tube
** ATF 10ft. 5 hole tube
3 Anti-Roost Bracket
4 Clamp
5 Line Charger
6 Hanger
7 3/32" Cable Clamp
8 Spring
9 3/32" Cable
10 Charger Wire (165 ft.)
Charger Wire (330 ft.)
11 Poultry Trainer
12 3/8" Hex Nut
13 3/8" Flat Washer
*Round up to the nearest 10'. Auger lengths from 50 to 500
feet. Example: 6820-200 would be a 200' roll of Auger
* USE together for 3 pans per 20 ft.
** USE together for 5 pans per 20 ft.

Power Unit Components

Item Description
1 Pinion Assembly
2 Cord Assembly
3 Connector (90 Degree)
4 "S" Hook
5 Motor
6 5/16-18 x 5/8 Hex Hd Screw
7 Gearhead
8 Pipe Plug

Power Unit Assembly Part Numbers

Part Number
3259-34
3259-39
3259-98
3259-100
56
Part No.
Auger 6820-0
53628-1
53628-4
53628-2
53628-3
53628-5
53628-6
29516
29520
29317
4207
1826
7551
4973
28994-165
28994-330
29333
1549
4976
3259-34 3259-39
Part No. Part No.
5046 5046
---- ----
4228 4228
2805 2805
4229 5703
4412-1 4412-1
3261-5 3261-5
3516 3516
6
HP RPM
1/3 HP 348 RPM Single Phase 60 Hz
1/2 HP 348 RPM Single Phase 60 Hz
1/2 HP 348 RPM Single Phase 50 Hz
1/2 HP 348 RPM Three Phase
MODEL ATF™ and MODEL ATF™ PLUS Feeding System
3259-98 3259-100
Part No. Part No.
5046 5046
28028 ----
-- ----
2805 2805
5977 28031
4412-1 4412-1
3261-11 3261-11
3516 3516
8
7
Phase Hz Voltage
230
230
230
50 Hz 220/380 Use with both Control Units
4
3
1
Usages
Use with both Control Units
Use with both Control Units
Use with both Control Units
5
MF2505A
