MODEL ATF™ and MODEL ATF™ PLUS Feeding System

Cable Installation

Important! Special Support Required at Hopper Location if the Hopper is not directly under a Truss.
Special Support at Hopper Locations (Wood Construction)
Figure 7.Cable Installations at Hopper Locations (Wood Construction)
Special Support at Hopper Location (Steel Truss)
Item Description
1 Feeder Line
2 Center of Hopper
Metal Hopper
3
4 Plastic Hopper
MF2505A
3
5
4
2
6
4
2
Item
5 Angle Iron: Long enough to
span 2 Trusses.
6 3/8" [9.5mm] Thick Steel
Mounting Plate
7 Heavy Duty Pulley Assembly
(Part No. 2014)
Figure 8.Special Support at Hopper Location (Steel)
1
5
1
1
7
7
2
Description
Installation
Item Description
1 Feeder Line
2 Hopper Centered on Feed
Line
3 Metal Hopper
4 Plastic Hopper
5 2" x 8" [50x200mm]
Board Spanning 3 Trusses
6 Heavy Duty Pulley
Assembly (Part No. 2014)
3
5
6
1
15
