Icom ID-RP2010V Service Manual page 50

• RF UNIT ASSEMBLY
MP91 (CHASSIS) ×15
(8810008661)
Torque: 0.5 N·m (±0.07 N·m)
Torque: 0.5 N·m (±0.07 N·m)
MP60 (CHASSIS)
MP60 (CHASSIS)
(8810007131)
(8810007131)
MP53 (CHASSIS) ×9
MP52 (CHASSIS) ×10 (8810008661)
(8810008661)
MP47 (CHASSIS) MP47 (CHASSIS)
(8810009050) (8810009050)
Torque: 0.5 N·m (±0.07 N·m) Torque: 0.5 N·m (±0.07 N·m) Torque: 0.5 N·m (±0.07 N·m) Torque: 0.5 N·m (±0.07 N·m)
MP11 (CHASSIS) MP11 (CHASSIS)
(8930100220) (8930100220)
MP101 (CHASSIS)
(8010025110)
Crown washer
(Comes with W131)
(Comes with W131)
Torque: 0.8 N·m (±0.1 N·m)
Legend:
Ref. No.
Unit Name
MP1 (CHASSIS)
(1234567890)
Parts No.
Top view
MP104 (CHASSIS)
(8510022900)
MP53 (CHASSIS) ×9
(8810008661)
RF-RX UNIT
RF-TX UNIT
W51 (CHASSIS)
(8920003070)
MP13 (CHASSIS)
(8850000140)
MP14 (CHASSIS)
(8850000430)
MP12 (CHASSIS)
(8820000530)
J2 (CHASSIS)
(6510000330)
MF1 (CHASSIS)
J1 (CHASSIS)
(2710001060)
(6510000330)
MP18 (CHASSIS)
(8810008661)
Nut
Bottom view
MP55 (CHASSIS) ×15
(8810008661)
W204 (CHASSIS)
(8910000220)
MP61 (CHASSIS)
(8950003640)
MP61 (CHASSIS)
(8950003640)
MP87 (CHASSIS)
(8930071690)
MP200 (CHASSIS) MP200 (CHASSIS)
MP101 (CHASSIS)
(8010025110)
EP1 (CHASSIS)
MP13 (CHASSIS)
(6910025930)
(8850000140)
Torque: 1.0 N·m (±0.15 N·m)
MP17 (CHASSIS) ×4
(8810010580)
8-4
MAIN UNIT
MP201 (CHASSIS)
(8930105760)
W131 (CHASSIS)
(8920002430)
Crown washer
(Comes with W131)
Torque: 0.8 N·m (±0.1 N·m)
(8930105770) (8930105770)
(Comes with W131)
MP11 (CHASSIS) MP11 (CHASSIS)
(8930100220) (8930100220)
J2 (CHASSIS) J2 (CHASSIS)
(6510000330) (6510000330)
J1 (CHASSIS)
(6510000330)
MP18 (CHASSIS)
(8810008661)
MP18 (CHASSIS)
(8810008661)
MP14 (CHASSIS) MP12 (CHASSIS)
(8850000430) (8820000530)
Unless otherwise noted, the tighten to torque is 0.7 N·m (±0.1 N·m).
Nut
MF1 (CHASSIS)
(2710001060)
EP1 (CHASSIS)
(6910025930)
Torque: 1.0 N·m (±0.15 N·m)
MP17 (CHASSIS) ×4
(8810010580)
