Icom ID-RP2010V Service Manual page 35

[MAIN UNIT]
REF PART
NO. NO.
L3052 6200009220 S.COI LQW18AN15NG00D
(LQW1608A15NG00)
L3073 6200010910 S.COI LQW18AN56NG00D
L3081 6200010910 S.COI LQW18AN56NG00D
L3082 6200009290 S.COI LQW18AN47NG00D
(LQW1608A47NG00)
L3141 6200011860 S.COI LQW18ANR47G00D
L3142 6200011860 S.COI LQW18ANR47G00D
L3143 6200011860 S.COI LQW18ANR47G00D
L3151 6200015510 S.COI LQW2BASR56J00L
L3152 6200015470 S.COI LQW2BASR39J00L
L3153 6200013860 S.COI MLK1005S12NJT
L3201 6200010660 S.COI C2520C-R15G-A (0.15U)
L3202 6200010660 S.COI C2520C-R15G-A (0.15U)
L3503 6200009220 S.COI LQW18AN15NG00D
(LQW1608A15NG00)
L3504 6200009070 S.COI LQW18AN18NG00D
(LQW1608A18NG00)
L7101 6200013830 S.COI MLK1005S22NJT
L7102 6200013830 S.COI MLK1005S22NJT
L7103 6200013840 S.COI MLK1005S18NJT
L7104 6200013850 S.COI MLK1005S15NJT
L7151 6200013770 S.COI MLK1005S68NJT
L7152 6200013770 S.COI MLK1005S68NJT
L7202 6140002551 S.COI #617DB-1919=P3
L7301 6200011670 S.COI LQW18AN82NG00D
L7302 6200011650 S.COI LQW18AN68NG00D
L7306 6200011860 S.COI LQW18ANR47G00D
L7307 6200011860 S.COI LQW18ANR47G00D
L7321 6200011800 S.COI C2520C-47NG-A
L7322 6200010780 S.COI C2520C-1R0G-A
L7351 6140005440 S.COI #617DB-1655
L7510 6140005440 S.COI #617DB-1655
L8621 6200011860 S.COI LQW18ANR47G00D
L8622 6200010810 S.COI C2520C-2R2G-A
L8623 6200010810 S.COI C2520C-2R2G-A
L8624 6130003000 S.COI #617DB-1714=P3
L8625 6200011860 S.COI LQW18ANR47G00D
L8641 6200011860 S.COI LQW18ANR47G00D
L8642 6200010780 S.COI C2520C-1R0G-A
L8643 6200010780 S.COI C2520C-1R0G-A
L8644 6130003000 S.COI #617DB-1714=P3
L8645 6200011860 S.COI LQW18ANR47G00D
L8661 6200011860 S.COI LQW18ANR47G00D
L8662 6200011450 S.COI C2520C-R39G-A
L8663 6200011450 S.COI C2520C-R39G-A
L8664 6200010910 S.COI LQW18AN56NG00D
L8665 6200010910 S.COI LQW18AN56NG00D
L8731 6200017280 S.COI MLK1005SR12JT
L8801 6200017530 S.COI NLV25T-100J-EF
L8802 6200017530 S.COI NLV25T-100J-EF
R3 7030016110 S.RES RMC1/16S-473JTH (47 k)
R4 7030016110 S.RES RMC1/16S-473JTH (47 k)
R6 7030016110 S.RES RMC1/16S-473JTH (47 k)
R7 7030016110 S.RES RMC1/16S-473JTH (47 k)
R12 7030016110 S.RES RMC1/16S-473JTH (47 k)
R15 7030016090 S.RES RMC1/16S-223JTH (22 k)
R16 7030016290 S.RES RMC1/16S-222JTH (2.2 k)
R17 7030016110 S.RES RMC1/16S-473JTH (47 k)
R19 7030016110 S.RES RMC1/16S-473JTH (47 k)
R20 7030016110 S.RES RMC1/16S-473JTH (47 k)
R21 7030016110 S.RES RMC1/16S-473JTH (47 k)
R22 7030016110 S.RES RMC1/16S-473JTH (47 k)
R23 7030016110 S.RES RMC1/16S-473JTH (47 k)
R24 7030015970 S.RES RMC1/16S-103JTH (10 k)
R25 7030016090 S.RES RMC1/16S-223JTH (22 k)
R27 7030016020 S.RES RMC1/16S-104JTH (100 k)
R30 7030016020 S.RES RMC1/16S-104JTH (100 k)
R31 7030016020 S.RES RMC1/16S-104JTH (100 k)
R34 7030016020 S.RES RMC1/16S-104JTH (100 k)
R36 7030016090 S.RES RMC1/16S-223JTH (22 k)
R37 7030016090 S.RES RMC1/16S-223JTH (22 k)
R38 7030016090 S.RES RMC1/16S-223JTH (22 k)
R39 7030016020 S.RES RMC1/16S-104JTH (100 k)
R40 7030016020 S.RES RMC1/16S-104JTH (100 k)
R41 7030016020 S.RES RMC1/16S-104JTH (100 k)
R45 7030016110 S.RES RMC1/16S-473JTH (47 k)
R46 7030016110 S.RES RMC1/16S-473JTH (47 k)
R47 7030016110 S.RES RMC1/16S-473JTH (47 k)
R101 7030015970 S.RES RMC1/16S-103JTH (10 k)
R102 7030015970 S.RES RMC1/16S-103JTH (10 k)
R103 7030015970 S.RES RMC1/16S-103JTH (10 k)
R105 7030016110 S.RES RMC1/16S-473JTH (47 k)
R107 7030015970 S.RES RMC1/16S-103JTH (10 k)
R108 7030016250 S.RES RMC1/16S-220JTH (22)
R109 7030016150 S.RES RMC1/16S-100JTH (10)
R110 7030016150 S.RES RMC1/16S-100JTH (10)
R111 7030016150 S.RES RMC1/16S-100JTH (10)
R112 7030016150 S.RES RMC1/16S-100JTH (10)
R113 7030016150 S.RES RMC1/16S-100JTH (10)
R114 7030016150 S.RES RMC1/16S-100JTH (10)
R115 7030016150 S.RES RMC1/16S-100JTH (10)
R116 7030016150 S.RES RMC1/16S-100JTH (10)
R117 7030016150 S.RES RMC1/16S-100JTH (10)
R118 7030016150 S.RES RMC1/16S-100JTH (10)
R119 7030016150 S.RES RMC1/16S-100JTH (10)
R120 7030016150 S.RES RMC1/16S-100JTH (10)
R121 7030016150 S.RES RMC1/16S-100JTH (10)
R122 7030016150 S.RES RMC1/16S-100JTH (10)
R123 7030016150 S.RES RMC1/16S-100JTH (10)
R124 7030016150 S.RES RMC1/16S-100JTH (10)
R125 7030015970 S.RES RMC1/16S-103JTH (10 k)
R126 7030016250 S.RES RMC1/16S-220JTH (22)
R127 7030016250 S.RES RMC1/16S-220JTH (22)
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
T 70.8/17.4
T 81.8/18.9
T 79.2/15.5
T 85.0/16.2
T 19.0/21.7
T 17.6/23.8
T 19.0/27.3
T 19.4/30.3
T 17.0/33.9
T 13.2/33.8
T 14.7/46.3
T 14.7/57.2
T 74.0/18.1
T 76.0/18.9
T 65.2/45.2
T 63.1/46.5
T 61.7/46.1
T 59.4/45.6
T 57.4/44.4
T 56.0/44.8
T 50.8/47.1
T 20.7/57.7
T 21.5/54.9
T 22.2/52.1
T 21.9/48.5
T 14.1/63.2
T 20.1/62.5
T 13.0/74.4
T 61.5/74.0
T 103.1/36.3
T 100.3/35.6
T 95.2/39.7
T 86.7/37.2
T 79.8/36.5
T 79.6/41.5
T 80.9/44.6
T 79.0/52.1
T 82.2/60.6
T 89.1/59.8
T 85.5/65.2
T 87.5/67.7
T 80.1/65.8
T 63.2/68.8
T 65.2/69.6
T 58.5/55.2
T 10.2/107.9
T 16.4/109.7
T 174.6/58.3
T 159.4/68.0
T 174.4/51.0
T 176.7/52.1
T 169.3/43.5
T 146.5/49.2
T 157.5/43.4
T 150.6/48.6
T 156.4/43.4
T 162.1/68.0
T 161.2/68.0
T 163.0/68.0
T 160.3/68.0
T 158.5/68.0
T 155.5/43.4
T 174.6/62.8
T 174.6/64.6
T 176.8/60.1
B 155.3/49.6
T 150.3/58.7
T 150.3/57.8
T 150.3/59.6
T 156.0/68.0
T 157.0/68.0
T 155.0/68.0
T 157.8/66.2
B 154.7/57.9
B 154.7/57.0
T 159.1/42.8
T 168.3/43.5
T 167.0/68.0
T 168.0/68.0
T 159.1/43.8
T 150.6/49.9
T 147.3/74.8
T 145.3/74.3
T 147.3/73.7
T 145.3/73.2
T 147.3/72.6
T 145.3/72.1
T 147.3/71.5
T 145.3/71.0
T 147.3/70.4
T 145.3/69.9
T 147.3/69.3
T 145.3/68.8
T 147.3/68.2
T 145.3/67.7
T 147.3/67.1
T 145.3/66.6
T 150.3/60.5
T 147.3/62.4
T 145.3/61.9
H/V REF PART
NO. NO.
R128 7030016250 S.RES
R129 7030016250 S.RES
R130 7030016250 S.RES
R131 7030016250 S.RES
R132 7030016250 S.RES
R133 7030016250 S.RES
R134 7030016250 S.RES
R135 7030016250 S.RES
R136 7030016250 S.RES
R137 7030016250 S.RES
R140 7030015970 S.RES
R141 7030018420 S.RES
R150 7030016060 S.RES
R151 7030015930 S.RES
R158 7030015970 S.RES
R159 7030015970 S.RES
R160 7030015970 S.RES
R161 7030015970 S.RES
R162 7030015970 S.RES
R163 7030016020 S.RES
R164 7030016470 S.RES
R165 7030016250 S.RES
R166 7030016250 S.RES
R167 7030016250 S.RES
R168 7030016560 S.RES
R171 7030016500 S.RES
R172 7030015990 S.RES
R173 7030015970 S.RES
R181 7030016110 S.RES
R182 7030016110 S.RES
R183 7030016110 S.RES
R184 7030016110 S.RES
R185 7030016110 S.RES
R186 7030016110 S.RES
R191 7030016290 S.RES
R192 7030016290 S.RES
R201 7030016220 S.RES
R202 7030016090 S.RES
R203 7030016440 S.RES
R204 7030016110 S.RES
R252 7030016110 S.RES
R253 7030015960 S.RES
R254 7030015960 S.RES
R281 7030016150 S.RES
R282 7030016150 S.RES
R285 7030016150 S.RES
R286 7030016150 S.RES
R289 7030015970 S.RES
R301 7030016560 S.RES
R302 7030016560 S.RES
R303 7030016560 S.RES
R304 7030015970 S.RES
R305 7030016290 S.RES
R308 7030016250 S.RES
R310 7030016020 S.RES
R311 7030016110 S.RES
R312 7030016110 S.RES
R313 7030016110 S.RES
R314 7030016110 S.RES
R315 7030016110 S.RES
R316 7030016290 S.RES
R317 7030016110 S.RES
R318 7030016110 S.RES
R319 7030016110 S.RES
R320 7030016020 S.RES
R321 7030016110 S.RES
R322 7030016020 S.RES
R323 7030016150 S.RES
R331 7030016110 S.RES
R332 7030016110 S.RES
R333 7030016110 S.RES
R334 7030016110 S.RES
R335 7030016110 S.RES
R336 7030016110 S.RES
R337 7030016110 S.RES
R341 7030016110 S.RES
R342 7030016110 S.RES
R371 7030016110 S.RES
R372 7030016110 S.RES
R373 7030016110 S.RES
R374 7030016020 S.RES
R375 7030016110 S.RES
R376 7030016110 S.RES
R377 7030016020 S.RES
R378 7030016110 S.RES
R379 7030016110 S.RES
R380 7030016110 S.RES
R381 7030016110 S.RES
R382 7030016110 S.RES
R383 7030016110 S.RES
R384 7030016110 S.RES
R385 7030015970 S.RES
R386 7030015970 S.RES
R394 7030016110 S.RES
R395 7030016110 S.RES
R396 7030016110 S.RES
R397 7030016110 S.RES
R431 7030016020 S.RES
R432 7030016020 S.RES
R433 7030016020 S.RES
R434 7030016020 S.RES
R435 7030016110 S.RES
R440 7030016150 S.RES
R441 7030016150 S.RES
R442 7030016150 S.RES
R443 7030016150 S.RES
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
7-3
DESCRIPTION M.
RMC1/16S-220JTH (22) T 147.3/61.3
RMC1/16S-220JTH (22) T 145.3/60.7
RMC1/16S-220JTH (22) T 147.3/60.2
RMC1/16S-220JTH (22) T 145.3/59.6
RMC1/16S-220JTH (22) T 147.3/59.1
RMC1/16S-220JTH (22) T 145.3/58.5
RMC1/16S-220JTH (22) T 147.3/58.0
RMC1/16S-220JTH (22) T 145.3/57.4
RMC1/16S-220JTH (22) T 147.4/56.9
RMC1/16S-220JTH (22) T 145.3/56.3
RMC1/16S-103JTH (10 k) T 173.7/46.6
RMC1/16K562FTP (5.6 k) T 161.3/43.0
RMC1/16S-105JTH (1 M) T 165.0/44.5
RMC1/16S-471JTH (470) T 163.2/44.5
RMC1/16S-103JTH (10 k) T 179.8/37.3
RMC1/16S-103JTH (10 k) T 186.6/39.3
RMC1/16S-103JTH (10 k) T 179.4/39.8
RMC1/16S-103JTH (10 k) T 186.6/38.3
RMC1/16S-103JTH (10 k) T 179.4/38.8
RMC1/16S-104JTH (100 k) T 186.6/40.3
RMC1/16S-390JTH (39) T 174.6/59.2
RMC1/16S-220JTH (22) T 174.6/61.0
RMC1/16S-220JTH (22) T 174.6/61.9
RMC1/16S-220JTH (22) T 174.6/60.1
RMC1/16SJPTH T 169.6/68.0
RMC1/16S-562JTH (5.6 k) T 182.8/34.6
RMC1/16S-683JTH (68 k) T 182.8/33.0
RMC1/16S-103JTH (10 k) T 183.9/34.6
RMC1/16S-473JTH (47 k) T 153.6/74.4
RMC1/16S-473JTH (47 k) T 153.6/73.5
RMC1/16S-473JTH (47 k) T 153.6/72.6
RMC1/16S-473JTH (47 k) T 164.5/72.5
RMC1/16S-473JTH (47 k) T 164.5/71.4
RMC1/16S-473JTH (47 k) T 164.5/70.5
RMC1/16S-222JTH (2.2 k) T 166.8/72.6
RMC1/16S-222JTH (2.2 k) T 166.8/73.5
RMC1/16S-563JTH (56 k) T 183.2/58.7
RMC1/16S-223JTH (22 k) T 183.2/59.6
RMC1/16S-272JTH (2.7 k) T 183.2/60.5
RMC1/16S-473JTH (47 k) T 181.9/58.2
RMC1/16S-473JTH (47 k) T 168.9/75.4
RMC1/16S-472JTH (4.7 k) T 166.4/75.4
RMC1/16S-472JTH (4.7 k) T 166.5/81.0
RMC1/16S-100JTH (10) T 197.4/17.0
RMC1/16S-100JTH (10) T 198.9/17.0
RMC1/16S-100JTH (10) T 192.9/17.0
RMC1/16S-100JTH (10) T 194.4/17.0
RMC1/16S-103JTH (10 k) T 153.1/68.0
RMC1/16SJPTH T
RMC1/16SJPTH T 109.2/101.9
RMC1/16SJPTH T 108.5/106.4
RMC1/16S-103JTH (10 k) T 122.4/86.0
RMC1/16S-222JTH (2.2 k) T 123.3/93.8
RMC1/16S-220JTH (22) T 106.8/73.6
RMC1/16S-104JTH (100 k) T 198.7/39.8
RMC1/16S-473JTH (47 k) T 193.6/40.2
RMC1/16S-473JTH (47 k) T 204.2/47.5
RMC1/16S-473JTH (47 k) T 204.2/48.4
RMC1/16S-473JTH (47 k) T 192.6/53.5
RMC1/16S-473JTH (47 k) T 193.5/54.4
RMC1/16S-222JTH (2.2 k) T 204.2/51.1
RMC1/16S-473JTH (47 k) T
RMC1/16S-473JTH (47 k) T 209.5/31.8
RMC1/16S-473JTH (47 k) T 208.0/31.8
RMC1/16S-104JTH (100 k) T 206.3/37.0
RMC1/16S-473JTH (47 k) T 187.5/45.8
RMC1/16S-104JTH (100 k) T 187.5/49.8
RMC1/16S-100JTH (10) T 187.5/52.3
RMC1/16S-473JTH (47 k) T 110.8/102.3
RMC1/16S-473JTH (47 k) T 112.1/102.3
RMC1/16S-473JTH (47 k) T 113.4/102.3
RMC1/16S-473JTH (47 k) T 111.6/112.9
RMC1/16S-473JTH (47 k) T 112.9/113.2
RMC1/16S-473JTH (47 k) T 113.8/113.2
RMC1/16S-473JTH (47 k) T 108.5/100.1
RMC1/16S-473JTH (47 k) T 204.2/49.3
RMC1/16S-473JTH (47 k) T 204.2/50.2
RMC1/16S-473JTH (47 k) T 196.8/54.2
RMC1/16S-473JTH (47 k) T 195.8/54.2
RMC1/16S-473JTH (47 k) T
RMC1/16S-104JTH (100 k) T 87.6/103.1
RMC1/16S-473JTH (47 k) T 87.6/101.8
RMC1/16S-473JTH (47 k) T 87.5/100.9
RMC1/16S-104JTH (100 k) T
RMC1/16S-473JTH (47 k) T 194.8/54.2
RMC1/16S-473JTH (47 k) T
RMC1/16S-473JTH (47 k) T 102.8/87.7
RMC1/16S-473JTH (47 k) T 108.5/105.5
RMC1/16S-473JTH (47 k) T 107.7/109.7
RMC1/16S-473JTH (47 k) T 108.5/107.3
RMC1/16S-473JTH (47 k) T 107.7/110.6
RMC1/16S-103JTH (10 k) T
RMC1/16S-103JTH (10 k) T
RMC1/16S-473JTH (47 k) T 109.2/101.0
RMC1/16S-473JTH (47 k) T 109.0/102.8
RMC1/16S-473JTH (47 k) T 109.0/103.7
RMC1/16S-473JTH (47 k) T 109.0/104.6
RMC1/16S-104JTH (100 k) T 101.6/112.7
RMC1/16S-104JTH (100 k) T 100.7/112.7
RMC1/16S-104JTH (100 k) T
RMC1/16S-104JTH (100 k) T
RMC1/16S-473JTH (47 k) T 91.7/129.9
RMC1/16S-100JTH (10) T
RMC1/16S-100JTH (10) T 100.0/90.9
RMC1/16S-100JTH (10) T 100.6/92.4
RMC1/16S-100JTH (10) T 101.1/90.9
H/V
LOCATION
96.3/92.4
211.0/31.8
89.0/94.5
94.4/112.7
89.0/93.6
93.5/112.7
92.6/112.7
99.8/112.7
98.9/112.7
99.5/92.4
