6-2 TRANSMIT ADJUSTMENTS AND VERIFICATIONS

* The repeater automatically transmits while pushing the PC's [←], [→], or [ENTER] key. Be sure to select the appropriate power range
before pushing keys.
ADJUSTMENT
IDLING
-Adjustment (Auto)-
TX OUTPUT POWER
-Adjustment (Manual)-
TX BALANCE
-Adjustment (Manual)-
ALC/DRIVE
-Adjustment (Auto)-
ITEM NAME
1 [VDL IDL Set]
2
[VHF FIDV]
3 [VHF DIDV]
1 [TX Total VHF Gain] • Transmitting
2
[POWER VHF2 MIN]
3 [POWER VHF2 1%]
4 [POWER VHF2 10%]
5 [POWER VHF2 50%]
6 [POWER VHF2
100%]
1 [POWER VHF1 100%] • Transmitting
2
[POWER VHF3
100%]
1 [ALC VHF]
2
[DRIVE VHF]
REPEATER'S
CONDITION
• Transmitting • Connect the RF power meter* to
the TX antenna connector.
• Connect the audio generator and
AC millivoltmeter to the [SERVICE]
jack (MIC line), and set it to:
Frequency: 1.5 kHz
Level:
• Push the PC's [ENTER] key.
• Connect the RF power meter* to
the TX antenna connector.
• Connect the audio generator and
AC millivoltmeter to the [SERVICE]
jack (MIC line), and set it to:
Frequency: 1.5 kHz
Level:
• Push the PC's [←] or [→] key to
adjust, then push the [ENTER] key.
• Connect the RF power meter* to
the TX antenna connector.
• Connect the audio generator and
AC millivoltmeter to the [SERVICE]
jack (MIC line), and set it to:
Frequency: 1.5 kHz
Level:
• Push the PC's [←] or [→] key to
adjust, then push the [ENTER] key.
• Transmitting • Connect the RF power meter* to
the TX antenna connector.
6-6
OPERATION
30 mVrms
30 mVrms
30 mVrms
VALUE
"OK" is displayed
in the Result row.
12.5 W
0.25 W
2.5 W
12.5 W
25 W
25 W
"OK" is displayed
in the Result row.
