5.2. Device Configuration

The hardware components to reproduce the connection procedures in this guide are as
follows:
The DeviceNet Slave (made up of DRT2-OD16 and XWT-ID16) produced by OMRON is used
in this guide as an example of a connected device via DeviceNet.
Personal computer
(Sysmac Studio,
Network Configurator and
SYCON.net installed,
OS: Windows 7)
USB cable (1)
Manufacturer
NJ-series CPU Unit
OMRON
(Built-in EtherNet/IP port)
Power Supply Unit
OMRON
Switching hub
OMRON
－ Switching hub power supply (24 VDC)
Sysmac Studio
OMRON
Network Configurator
OMRON
－ Personal computer (OS: Windows 7)
USB cable (1)
－
(USB 2.0 type B connector)
－ LAN cable (STP (shielded, twisted-pair)
cable of Ethernet category 5 or higher)
netTAP
Hilscher
Firmware (for netTAP)
Hilscher
USB cable (2)
－
(USB 2.0 mini B connector)
EDS file (for netTAP)
Hilscher
Configuration and diagnosis software
Hilscher
－ netTAP power supply (24 VDC)
DeviceNet Slave (remote I/O terminal
OMRON
with 16 transistor outputs + expansion
unit with 16 transistor inputs)
EDS file (for DeviceNet Slave)
OMRON
DeviceNet cable
OMRON
T-branch tap
OMRON
Communications power supply
－
(24 VDC)
I/O power supply (24 VDC)
－
5．Applicable Devices and Device Configuration
netTAP power supply
NJ501-1500
(Built-in EtherNet/IP port)
Switching hub
power supply
W4S1-05C
USB cable (2)
Name
NT100-RE-DN
Communications
power supply
T-branch tap
(DCN1-1C)
DeviceNet
Model
NJ501-1500
NJ-PA3001
W4S1-05C
－
SYSMAC-SE2□□□
(provided in Sysmac Studio
package)
－
－
－
NT 100-RE-DN
NTEISDNM.NXF
－
HILSCHER NT 100-RE EIS
V1.1.EDS
SYCON.net
－
DRT2-OD16 + XWT-ID16
DRT2-OD16+XWT-ID16.eds
(provided in Sysmac Studio
package)
DCA1-5C10
DCN1-1C
－
－
DeviceNet Slave
DRT2-OD16 +
XWT-ID16
I/O power supply
cable
Version
Ver.1.18
Ver.1.0
Ver.1.22
Ver.3.64
Ver.1.01
Ver.1.7.0.8
Ver.1.1
Ver.1.400
