Omron sysmac EtherNet/IP NJ Series Connection Manual page 50

7.4.3. Tag Registration
Import the created CSV file for use with Network Configurator, and register tags and tag sets.
1
Right-click Controller (Node 1)
in the Network Configuration
Pane and select Parameter –
Edit from the menu.
2
The Edit Device Parameters
Dialog Box is displayed.
Check that the Connections
Tab is selected.
Click To/From File.
3
Select Import from File.
4
The Import Connection
Configuration Dialog Box is
displayed.
Select EIP002.csv and click
Open.
*"EIP002.csv" is the file
created in step 6 of 7.3.2.
Global Variable Settings.
7．EtherNet/IP Connection Procedure
47
