17
After performing step 16, the
following gateway and firmware
are displayed.
- Required gateway:
NT 100-RE-DN
- Available Firmware:
NTEISDNM.NXF
18
If the available firmware
displayed in step 17 is not
downloaded, use the following
steps to download the firmware.
Click Browse to the right of
Available Firmware.
*There is no need to perform
steps from 18 to 22 if the
available firmware is already
downloaded to netTAP.
In that case, click OK at the
bottom of the Settings Pane to
finish the gateway
configuration of netTAP.
19
Select NTEISDNM.NXF from
the Select Firmware File Dialog
Box.
Click Open.
20
The Download Button is now
available. Click Download to
download the firmware into
netTAP.
21
The dialog box on the right is
displayed. Confirm that there is
no problem, and click Yes.
The firmware download starts.
7．EtherNet/IP Connection Procedure
...
