6.4. Hilscher netTAP Settings

The parameters of the netTAP are shown below.
Data length for EtherNet/IP communications (tag data links)
Produced data len. (number of send bytes)
Consumed data len. (number of receive bytes)
DeviceNet communications settings
Setting item
Node address (MAC ID)
Baud rate
Signal mapping
The signal (I/O data) mapping between Port X2 (EtherNet/IP communications) and Port X3
(DeviceNet communications) is shown below.
EtherNet/IP
Send (Input_101: output tag set)
To
~2 InBytes.BYTE_0001
Controller
~2 InBytes.BYTE_0002
Receive (Output_100: input tag set)
From
~2 OutBytes.BYTE_0001
Controller
~2 OutBytes.BYTE_0002
Additional Information
For more information on I/O data mapping (Port X2) to set tag data links between the
Controller and the netTAP, refer to the Operating Instruction Manual Configuration of
Gateway and Proxy Devices netTAP, netBRICK and netLINK (DOC081201OI10EN).
Setting item
netTAP
0
125 kBits/s
netTAP
Port X2 (EtherNet/IP)
6．EtherNet/IP Settings
Data length
2 bytes
2 bytes
DeviceNet Slave
1
(No require to be set because it
is automatically detected.)
Port X3 (DeviceNet)
Receive
<- Input_001
<- Input_002
Send
-> Output_001
-> Output_002
DeviceNet
From
DeviceNet Slave
To
DeviceNet Slave
11
