5．Applicable Devices and Device Configuration
Precautions for Correct Use
Prepare the firmware for the netTAP listed on the previous page beforehand.
To obtain the firmware, contact Hilscher GmbH.
Precautions for Correct Use
Prepare the EDS file for the netTAP listed on the previous page beforehand.
To obtain the EDS file, contact Hilscher GmbH.
Precautions for Correct Use
When there is an icon file specific to the device, store the icon file and EDS file in the same
folder.
Precautions for Correct Use
Prepare the EDS file for the DeviceNet Slave listed on the previous page beforehand.
The EDS files for OMRON products are provided in the Sysmac Studio package.
Those EDS files are stored in the specific folder once you have installed Sysmac Studio.
Precautions for Correct Use
Update Sysmac Studio and Network Configurator to the versions specified in this Clause 5.2.
or to higher versions. If you use a version higher than the one specified, the procedures and
related screenshots described in Section 7. and the subsequent sections may not be
applicable. In that case, use the equivalent procedures described in this guide by referring to
the Sysmac Studio Version 1 Operation Manual (Cat. No. W504) and Network Configurator
Online Help.
Additional Information
For information on power supply specifications of the switching hub, refer to the Switching
Hub W4S1-series Users Manual (Cat. No. 0969584-7).
Additional Information
For information on power supply specifications of the netTAP, refer to the User Manual
netTAP NT 100 Gateway Devices (DOC081001UM18EN).
Additional Information
Refer to the User Manual netTAP NT 100 Gateway Devices (DOC081001UM18EN) for
information on DeviceNet such as communications power supply, cables, network wiring and
termination resistors at each end of the cable.
