Omron sysmac EtherNet/IP NJ Series Connection Manual page 51

5
If the dialog box on the right is
displayed, confirm that there is
no problem, and click Yes.
*If you select the Tag Sets Tab
in step 2 and click To/From
File, the dialog box on the
right is displayed.
6
If the dialog box on the right is
displayed, confirm that there is
no problem, and click No.
*In this guide, a tag set is not
automatically created from
the tags you import.
*If you select the Tag Sets Tab
in step 2 and click To/From
File, the dialog box on the
right is also displayed.
7
Click the Tag Sets Tab in the
Edit Device Parameters Dialog
Box.
Click the In - Consume Tab,
and then click Edit Tags.
*Follow steps 7 to 13 to
register the input tag set of
Controller (Node 1).
7．EtherNet/IP Connection Procedure
48
