Removal and Installation

Required Equipment

Table 4-1: Required equipment for Removal and Replacement

Item No. Name
1 Screwdriver handle
2
Screwdriver handle, extended
length, 10.5 to 12 inches
3 T-10 Torx tip
4 T-15 Torx tip
5 T-20 Torx tip
6 3/16 inch socket tip
7 1/8 inch flat-bladed screwdriver
8 #0 phillips screwdriver
9 Angle-Tip Tweezers
10 3/16 inch open-end wrench
DSA8300 Digital Serial Analyzer and Modules Service Manual
WARNING.
Before performing any procedure in this section, disconnect the power
cord from the line voltage source. Failure to do so could cause serious injury
or death.
Only Qualified personnel should perform service procedures. Before performing
this procedure, read the General and Service Safety summaries at the beginning
of this manual. To prevent possible injury to service personnel or damage to
electrical components, read Preventing ESD. (See page 4-1.)
NOTE.
Read the cleaning procedure before disassembling the instrument for
cleaning.
If you replace any circuit board, check to see if it is necessary to adjust the
instrument. (See Table 4-4 on page 4-58.)
Most assemblies in this instrument can be removed with a screwdriver handle
mounted with a size T-15, Torx® screwdriver tip. Use this tool whenever a
procedure step instructs you to remove or install a screw unless a different size
screwdriver is specified in that step.
Description
Accepts Torx®-driver bits
Accepts Torx®-driver bits and 3/16 socket tip. Used
for removing the T-10 screws and 3/16 inch hex posts
from the electrical and optical module slots.
Torx®-driver bit for T-10 size screw heads, used for
removing the electrical or optical module chassis.
Used for removing most the screws. Torx®-driver bit
for T-15 size screw heads.
Used for removing the handle hardware. Torx®-driver
bit for T-20 size screw heads.
Used for removing the 3/16 inch hex posts from the
electrical and optical module slots.
Screwdriver for unlocking cable connectors.
Screwdriver for removing small phillips screws, CD
and hard drive.
Used to remove front panel knobs.
Used to remove the rear panel nut posts.
Removal and Installation
Part number
General Tool: 620-440
Standard tool or Xcelite
99X10 V N/S#48706
General Tool: 640-235
General Tool: 640-247
General Tool: 640-250
Standard tool
Standard tool
Standard tool
Standard tool
Standard tool
