Replaceable Parts List

Table 5-3: Drives replaceable parts

Fig. & index Tektronix
number part number
5-2- 1 065-0890-00
-2 650-5395-00
-3 407-5555-00
-4 211-1081-00
-5
211-1050-00
-6 441-2636-00
-7 211-0950-00
-8 407-5288-00
-9 211-0738-00
-10 200-5079-00
-11 065-0807-01
-12 174-5650-00
-13 174-5349-00
-14 441-2550-00
-15 210-0457-00
5–6
Serial Serial
number number
effective discont'd
DSA8300 Digital Serial Analyzer and Modules Service Manual
Qty Name & description
1 HARD DRIVE ASSEMBLY KIT: INCLUDES ITEMS
2, 3, and 4
1 DRIVE ASSEMBLY: HARD DRIVE, PROGRAMMED
1197673XX
1
BRACKET; REMOVABLE HD BOTTOM
4 SCREW, MACHINE; M3 X 0.5 X 3.5MM, FLAT
WAFER HD W/SERRATIONS STRESS RELIEVED,
PHL, ZINC PLATED STEEL
2 SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD
PLT,T15
1 CHASSIS; DRIVE FRAME BOTTOM
2
SCREW,MACHINE; M2X.4X3L,PHL, PNH, STL NI PL
1 BRACKET,DVD-CD/RW;SATA ADAPTER FOR
SLIMLINE
2 SCREW,MACHINE; 6-32 X 0.625,PNH,STL BLK
ZI,TORX
1 COVER; CD
1 DISK DRIVE;OPTICAL, CD-RW/DVD R/RW,
16.7 MB/SEC, 650MEG/8.5GIG, SATA/ATAPI
1 CA ASSY, SATA-DVD, DATA AND POWER;
1 CA ASSY; SATA COMBO, HARD DRIVE CABLE
WITH LATCH;
1
CHASSIS; DRIVE FRAME CHASSIS TOP
4 NUT, PL, ASSEM WA; 6-32 X 0.312,
W/LOCKWASHER, STEEL, ZINC FINISH
