Removal and Installation
Table 4-1: Required equipment for Removal and Replacement (cont.)
Item No. Name
11
5/16 inch open-end wrench
12
Coaxial cable connector tool

External Assemblies

Figure 4-1: External assemblies

4–6
Description
Used to remove the rear panel nut posts.
Used to remove coaxial connectors from
d-subminiature connector housings.
WARNING.
Before performing any procedure in this section, disconnect the power
cord from the line voltage source. Failure to do so could cause serious injury
or death.
DSA8300 Digital Serial Analyzer and Modules Service Manual
Part number
Standard tool
Amp: 58095-1
