Table 5-6: Power Supply Replaceable Parts List - Tektronix DSA8300 Service Manual

Replaceable Parts List

Table 5-6: Power supply replaceable parts list

Fig. & Tektronix
index part
number number
5-5-1 441-2590-00
-2 119-5806-07
-3 211-1050-00
-4 131-8257-00
-5 131-0850-00
-6 210-0457-00
-7 210-0465-00
-8 650-4086-00
-9 210-1443-00
-10 136-0140-00
5–12
Serial Serial
number number
effective discont'd
DSA8300 Digital Serial Analyzer and Modules Service Manual
Qty Name & description
1 CHASSIS ASSEMBLY: MAIN
1 POWER SUPPLY; CUSTOM, AC-DC; 375W
8 SCREW, MACH: 6-32 X 0.312 L, PNH, T15
1 CONN, PANEL MOUNT; BNC TO MCX
2
CONN, JACK, RF; SMA, FEED THRU; DUAL
FEMALE, STR, 50 OHM, 0.25 MTG W/ 0.375 HEX,
0.59 X 0.24 MLG
1 NUT, PL, ASSEM WA: 6-32 X 0.312, W/LCKWSHR
1 NUT, PLAIN, HEX: 0.25-32 X 0.375
1 CA ASSEMBLY: ELECT, ANTI STATIC
1 WASHER, FLAT: 0.25 ID X 0.375 OD X 0.265
1 JACK, TIP: BANANA, CHARCOAL GRAY
