Removal and Installation
CD-RW/DVD and Hard Disk
Drive Mounting Frame
4–24
1. To access the frame, remove these assemblies:
Trim (all) (See page 4-9.)
Bottom cover (See page 4-10.)
Left and right covers (See page 4-10.)
CD-RW/DVD (See page 4-22.)
Hard drive (See page 4-20.)
2. To remove the mounting frame:
a. Place the instrument bottom on the work surface, so that you can access
the mounting drive frame. (See Figure 4-12.)
b. Remove the six T-15 Torx drive screws that attach the mounting frame
to the ATX chassis.
c. Remove the CDD/HDD drive cable from the hard drive.
d. Remove the CD-RW/DVD drive cable from the CD-RW/DVD drive.
e. Hold both far side corners of the drive frame; lift up and toward the rear
of the instrument simultaneously.
f. Gently shift the frame from side to side as you pull it to the rear until you
can remove it completely.
3. To reinstall the mounting frame: Reverse the steps. Refer to the cable
connections table for information about where to connect cables. (See
Table 5-1.)
