Table 4-2: Possible causes of instrument failure (cont.)
Failure symptom
Controller appears "dead"; power light comes
on, but monitor screen(s) is (are) blank
Flat LCD panel display blank
Front panel LEDs do not light
Hard disk drive related symptoms
CD-RW/DVD related symptoms
Diagnostic errors
Compensation errors
Modules not recognized
DSA8300 Digital Serial Analyzer and Modules Service Manual
Possible cause(s) / solutions
SO DIMMs incorrectly installed or missing.
Defective ATX board.
Check for a defective cable from Front-Panel board to Bridge board.
Check for a defective cable from Power PC board to Front-Panel board.
If an external monitor is plugged in to the DVI-I rear-panel output connector, check
for a display on the external monitor:
If there is no display, verify that the monitor is powered on. If the monitor is
powered on, the ATX circuit board assembly might need to be replaced.
If there is a display, the LCD assembly or the Power PC assembly might need to
be replaced.
Replace the Front-Panel board.
Defective hard disk drive.
Replaceable hard disk drive not installed.
Power supply failure.
Replaceable hard disk drive or optionally field installed fixed hard disk drive not
configured as bootable (slave) master hard disk drive.
Faulty benchtop controller.
Defective CD-RW/DVD.
Defective CD-RW/DVD drive cable.
Remove all electrical and optical modules from the instrument, then run
diagnostics again. If the instrument passes diagnostics, check for the electrical
and optical module that is causing the failures. Then run diagnostics again.
If the instrument fails the diagnostics without the installed modules, replace the
Time Base assembly, and then run diagnostics again.
Verify that each module is completely installed in the slot.
Remove all electrical and optical modules from the instrument, and then run
compensation again. If the instrument passes compensation, check for the
electrical and optical module that is causing the failure.
If the instrument still fails compensation, replace the Time Base assembly.
Module firmware incompatible with mainframe software version.
Faulty module. Refer to appropriate module service manual for further
troubleshooting information.
Module not fully installed in the slot.
