Theory of Operation
80C10B Optical Sampling
Module
80C11 Optical Sampling
Module
80C12 Optical Sampling
Module
2–12
The 80C10B module is designed to test long wavelength (1310 and 1550 nm)
signals. This module is intended to be used as a test and measurement tool for
high bandwidth telecommunications with its high optical bandwidth >80 GHz.
Supported standards or data filtering rates include OC-768 and FEC43.02
(G.709).
30 GHz: The sampler bandwidth and response is set during the calibration
such that the combined system will have an Optical Bandwidth (-6 dB)
>30 GHz.
65 GHz: The sampler bandwidth and response is set during the calibration
such that the combined system will have an Optical Bandwidth (-6 dB)
>65 GHz.
80 GHz: The sampler bandwidth and response is set during the calibration
such that the combined system will have an Optical Bandwidth (-6 dB)
>80 GHz.
There is no clock recovery option available.
The 80C11 module is designed to test long wavelength (1100-1650 nm) signals.
This module is intended to be used as a test and measurement tool for high
bandwidth telecommunications with its high optical bandwidth >20 GHz.
Supported standards or data filtering rates include
9.953/10.31/10.518/10.66/10.71/11.1 Gb/s.
Clock recovery options are available (9.953/10.66/10.71 Gb/s and
Continuous-rate from 9.8 Gb/s to 12.6 Gb/s).
The 80C12 module is designed to test both long and short wavelength
(700-1650 nm) signals. This module is intended to be used as a test and
measurement tool for high bandwidth telecommunications with its high optical
bandwidth >10 GHz.
There are three Reference Receiver filters selectable that are customer
specified from the following list of five rates: 1FC (FC1063) for 1.0625 Gb/s
Fibre Channel, 2FC (FC2125) for 2.125 Gb/s Fibre Channel, 10GBase-X4
for 3.125 Gb/s, VSR-5 for 3.31776 Gb/s, and 4FC (FC4250) for 4.25 Gb/s
Fibre Channel. Filterless, full-bandwidth settings (8.5 GHz and 9 GHz) are
also available.
In addition, this module offers the option to support 10 Gb/s optical standards
as well. This option is mutually exclusive with the sub-10 Gb/s filter options.
The standard reference receiver filter rates offered with the Option 10G are
SONET/SDH OC-192/STM-64, 10GBase-W, 10 Gb Ethernet (9.95338 Gb/s),
10GBase-R (10.3125 Gb/s), 10G Fibre Channel (10.51875 Gb/s), G.975
FEC (10.66 Gb/s), G.709 FEC (10.71 Gb/s), 10GBE FEC (11.0957 Gb/s),
