Figure 3-6 Removing A Hard Drive - Sun Microsystems Netra 440 Service Manual

10. Pinch the hard drive latch up to release the hard drive handle (
FIGURE 3-6
11. Pull the handle away from the hard drive until you feel the hard drive connector
disengage from the SCSI backplane connector (
12. Holding the hard drive by the handle, slide the hard drive out of the hard drive
bay.
Note – When you reinstall the hard drive (or a replacement drive), be sure to install
the hard drive into the same drive bay as the one from which it was just removed.
13. If you are not replacing the hard drive right away, close the system door.
48 Netra 440 Server Service Manual • August 2004
Removing a Hard Drive
SCC
).
FIGURE 3-6
).
FIGURE 3-6
