6. Raise the slotted PCI card retainer flap on the fan tray 3 assembly (
7. Locate the air diverter and SCSI backplane (
Air diverter
PCI card retainer flap
Removing the Air Diverter
FIGURE 4-13
8. Unscrew the two screws from the top of the air diverter and remove the air
diverter from the system (
).
FIGURE 4-13
Chapter 4 Removing and Replacing Cold-Swappable Components
).
FIGURE 4-13
Captive screws
SCSI backplane
).
FIGURE 4-13
69
