Sun Microsystems Netra 440 Service Manual page 148

TABLE B-6
Pin
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
130 Netra 440 Server Service Manual • August 2004
SCSI Port Pin Signals (Continued)
Signal Description
TERM_PWR
(N/C)
Ground
ATN +
Ground
BSY +
ACK +
RST +
MSG +
SEL +
CD +
REQ +
I/O +
Data8 +
Data9 +
Data10 +
Data11 +
Pin Signal Description
52 TERM_PWR
53 (N/C)
54 Ground
55 ATN –
56 Ground
57 BSY –
58 ACK –
59 RST –
60 MSG –
61 SEL –
62 CD –
63 REQ –
64 I/O –
65 Data8 –
66 Data9 –
67 Data10 –
68 Data11 –
