Alarm LEDs
The alarm LEDs are located at the front of the system, along the left side of the front
cover.
Critical Alarm LED
Major Alarm LED
Minor Alarm LED
User Alarm LED
FIGURE 1-6
The dry contact alarm card has four LED status indicators that are supported by
ALOM. Information about the alarm indicators and dry contact alarm states is
provided in
Advanced Lights Out Manager Software User's Guide for the Netra 440 Server (817-5481-
xx). For more information about an API to control the alarm indicators, refer to the
Netra 440 Server System Administration Guide (817-3884-xx).
Alarm LEDs
. For more information about alarm indicators, refer to the Sun
TABLE 1-5
Chapter 1 Identifying the Netra 440 Server FRUs and LEDs
