Alinx AXKU040 User Manual page 45

FMC_DP3_M2C_P
FMC_DP3_M2C_N
FMC_DP4_M2C_P
FMC_DP4_M2C_N
FMC_DP5_M2C_P
FMC_DP5_M2C_N
FMC_DP6_M2C_P
FMC_DP6_M2C_N
FMC_DP7_M2C_P
FMC_DP7_M2C_N
FMC_DP0_C2M_P
FMC_DP0_C2M_N
FMC_DP1_C2M_P
FMC_DP1_C2M_N
FMC_DP2_C2M_P
FMC_DP2_C2M_N
FMC_DP3_C2M_P
FMC_DP3_C2M_N
FMC_DP4_C2M_P
FMC_DP4_C2M_N
FMC_DP5_C2M_P
FMC_DP5_C2M_N
FMC_DP6_C2M_P
FMC_DP6_C2M_N
45 / 59
KINTEX UltraScale+ FPGA Board AXKU040 User Manual
MGTHRXP0_228
MGTHRXN0_228
MGTHRXP3_227
MGTHRXN3_227
MGTHRXP2_227
MGTHRXN2_227
MGTHRXP1_227
MGTHRXN1_227
MGTHRXP0_227
MGTHRXN0_227
MGTHTXP3_228
MGTHTXN3_228
MGTHTXP2_228
MGTHTXN2_228
MGTHTXP1_228
MGTHTXN1_228
MGTHTXP0_228
MGTHTXN0_228
MGTHTXP3_227
MGTHTXN3_227
MGTHTXP2_227
MGTHTXN2_227
MGTHTXP1_227
MGTHTXN1_227
E4 Transceiver Data 3 Input P
E3 Transceiver Data 3 Input N
F2 Transceiver Data 4 Input P
F1 Transceiver Data 4 Input N
H2 Transceiver Data 5 Input P
H1 Transceiver Data 5 Input N
K2 Transceiver Data 6 Input P
K1 Transceiver Data 6 Input N
M2 Transceiver Data 7 Input P
M1 Transceiver Data 7 Input N
Transceiver Data 0 Output
B6
P
Transceiver Data 0 Output
B5
N
Transceiver Data 1 Output
C4
P
Transceiver Data 1 Output
C3
N
Transceiver Data 2 Output
D6
P
Transceiver Data 2 Output
D5
N
Transceiver Data 3 Output
F6
P
Transceiver Data 3 Output
F5
N
Transceiver Data 4 Output
G4
P
Transceiver Data 4 Output
G3
N
Transceiver Data 5 Output
J4
P
Transceiver Data 5 Output
J3
N
Transceiver Data 6 Output
L4
P
L3 Transceiver Data 6 Output
