Alinx AXKU040 User Manual page 33

FMC1_LPC_LA28_N
FMC1_LPC_LA29_P
FMC1_LPC_LA29_N
FMC1_LPC_LA30_P
FMC1_LPC_LA30_N
FMC1_LPC_LA31_P
FMC1_LPC_LA31_N
FMC1_LPC_LA32_P
FMC1_LPC_LA32_N
FMC1_LPC_LA33_P
FMC1_LPC_LA33_N
FMC1_LPC_SCL
FMC1_LPC_SDA
The 2 FMC LPC Connectors Pin Assignment
nd
Signal Name
FMC2_LPC_CLK0_P
FMC2_LPC_CLK0_N
FMC2_LPC_CLK1_P
FMC2_LPC_CLK1_N
33 / 59
KINTEX UltraScale+ FPGA Board AXKU040 User Manual
IO_L17N_T2U_N9_AD10N_48
IO_L18P_T2U_N10_AD2P_48
IO_L18N_T2U_N11_AD2N_48
IO_L2P_T0L_N2_48
IO_L2N_T0L_N3_48
IO_L5P_T0U_N8_AD14P_48
IO_L5N_T0U_N9_AD14N_48
IO_L1P_T0L_N0_DBC_48
IO_L1N_T0L_N1_DBC_48
IO_L3P_T0L_N4_AD15P_48
IO_L3N_T0L_N5_AD15N_48
IO_T2U_N12_47
IO_T3U_N12_47
FPGA Pin Number
IO_L11P_T1U_N8_GC_64
IO_L11N_T1U_N9_GC_64
IO_L13P_T2L_N0_GC_
QBC_A06_D22_65
IO_L13N_T2L_N1_GC_
QBC_A07_D23_65
FMC Reference 28
AB34
Data N
FMC Reference 29
AC33
Data P
FMC Reference 29
AD33
Data N
FMC Reference 30
AE28
Data P
FMC Reference 30
AF28
Data N
FMC Reference 31
AD29
Data P
FMC Reference 31
AE30
Data N
FMC Reference 32
AE27
Data P
FMC Reference 32
AF27
Data N
FMC Reference 33
AC28
Data P
FMC Reference 33
AD28
Data N
Y21 FMC I2C Bus Clock
U29 FMC I2C Bus Data
FPGA Pin Description
Name
FMC Reference 1
AG12
Reference Clock P
FMC Reference 1
AH12
Reference Clock N
FMC Reference 2
P26
Reference Clock P
FMC Reference 2
N26
Reference Clock N
