KINTEX UltraScale+ FPGA Board AXKU040 User Manual
Figure 5-1: 156.25Mhz System Clock Source Schematic
System Clock pin assignments:
Signal Name
FPGA Pin
HDMI_DRU_CLOCK_P
H6
HDMI_DRU_CLOCK_N
H5
