Installation
3. Installation
3.1. Installing the Software
To create a configuration for the device , the CAN-Gateway Configurator running on a Windows system and the
Ixxat VCI driver are needed.
NOTICE
The VCI driver is constantly improved and expanded! Check if a newer version is available on
www.ixxat.com/driver-windows.
NOTICE
The CAN-Gateway Configurator is constantly improved and expanded! Check if a newer version is
available within the product support pages on www.ixxat.com/support-bridges-gateways.
1.
Install the latest VCI driver on a Windows computer (see Installation Guide VCI Driver).
2.
Download the CAN-Gateway Configurator CANbridge NT & CAN@net NT 100/200/420 package from the
product support pages on www.ixxat.com/support-bridges-gateways.
3.
Start the Ixxat CanGWconfig Setup.
• Installation wizard starts automatically.
4.
Follow the instructions in installation program.
• By default the package is stored in C:\Program Files\HMS\Ixxat CAN-Gateway Configurator V6.
• The examples for (LUAand configuration) are stored in C:\Users\Public\Documents\HMS\Ixxat CAN-
Gateway Configurator\Examples.
5.
Check the firmware version in C:\Users\Public\Documents\HMS\Ixxat CAN-Gateway
Configurator\Examples\firmware and check if a newer firmware version is available on
www.ixxat.com/support-bridges-gateways.
6.
If newer firmware is available, update the firmware (see
7.
In Windows Start menu open folder Ixxat CAN-Gateway Configurator V6 and start CAN-Gateway
Configurator V6.
3.2. Checking and Updating the Firmware
To use all features the latest firmware versions of the CAN-Gateway Configurator and of the CAN@net NT/
CANbridge NT must be installed.
Checking the Device Firmware
1.
Make sure, that the latest VCI driver is installed.
2.
Make sure, that the device is correctly connected to the host computer and to power supply.
3.
Make sure, that the latest CAN-Gateway Configurator is installed (check within product support pages on
www.ixxat.com/support-bridges-gateways.
4.
Start the Ixxat CAN-Gateway Configurator.
5.
Open menu Scan and select All Ixxat devices.
• Connected devices and firmware version of the devices are shown.
Updating the Device Firmware
IMPORTANT
Whether a password is needed, is defined in the security settings of the CAN-Gateway Configurator.
The default password is IXXAT. For more information see
4.02.0332.20001 Version 1.7
CAN-Gateway Configurator V6 for CAN@net NT and CANbridge NT
Updating the Device Firmware, p.
Security Settings, p. 52
7).
Page 7 of 56
