CAN-Gateway Configurator V6 for CAN@net NT and CANbridge NT
NOTICE
The firmware is constantly improved and expanded! Check if a newer firmware version is available
within the product support pages on www.ixxat.com/support-bridges-gateways.
If the current firmware of the device in use is V4 or older:
• See update package on the product support pages on
information about updating to V5 or contact Ixxat support.
If the current firmware of the device in use is V5 or V6:
1. Check if newer firmware is available on the product support pages on
www.ixxat.com/support-bridges-gateways.
2. Download and unzip the update package.
3. Make sure, that the device is connected to power supply.
4. Connect the device to the computer via USB.
5. Make sure that the latest CAN-Gateway Configurator is installed (check within product support pages on
www.ixxat.com/support-bridges-gateways).
6. Start the CAN-Gateway Configurator.
7. In drop down list Select device type select the device in use.
8. In drop down list Select device version select the current firmware version of the device V5 or V6.
The device is only found if the selected firmware version matches the firmware version of the connected
device.
9. Scan for devices with button Scan
10. Click button Connect
11. Open menu Target and select Read configuration from target.
12. Save the configuration on the computer.
13. Open menu Target and select Update Firmware.
14. Select the update file.
• Firmware of the connected device is updated.
15. In the status window check if the update is completed successfully.
16. If the device was updated from V5 to V6 , select V6 in drop-down list Select device version.
17. If using a V5 configuration, open menu File and select Convert V5 to V6 to convert the configuration to the
latest version.
18. Write the saved configuration to the device.
TIP
HMS recommends to verify configurations that are converted from V5 to V6, to make sure that all
settings are working correctly.
Page 8 of 56
and select the device in use in the combo box Target Device.
.
Checking and Updating the Firmware
www.ixxat.com/support-bridges-gateways for
