General Settings

2. To activate the new rules, execute the following command: udevadm control --reload-rules
3. To load a saved configuration file onto the CAN NT device, use the command line tool cangwfile. If the tool is
started without any command line parameters, a list of available commands and options is shown.
4. Write the configuration to the target device (see User Manual CAN-Gateway Configurator for more
information about the Command Line Tool).
5.2. General Settings
Figure 5. General settings
In the configuration tree in General the following settings can be enabled depending on the device in use and the
selected operational mode.
Setting Device
Lua ADK CAN@net NT 100/200/420
CANbridge NT 200/420
Syslog CAN@net NT 100/200/420
MQTT CAN@net NT 100/200/420
Remote access CAN@net NT 100/200/420
Expert Mode CAN@net NT 100/200/420
CANbridge NT 200/420
CAN tunnel CANbridge NT 420
In the CAN-Ethernet-CAN Bridge mode the settings can be enabled for each connected Master and Slave
individually.
4.02.0332.20001 Version 1.7
CAN-Gateway Configurator V6 for CAN@net NT and CANbridge NT
Operational Mode
Local CAN Bridge, CAN-Eth-CAN Bridge
Bridge
Local CAN Bridge, CAN-Eth-CAN Bridge
Local CAN Bridge, CAN-Eth-CAN Bridge
Local CAN Bridge, CAN-Eth-CAN Bridge
Local CAN Bridge, CAN-Eth-CAN Bridge, ASCII Gateway
Repeater/Star Coupler, Bridge
Bridge
