Action Rules
Possible Events
Event name Description
CAN message If this event is set, the defined action is triggered if the
received specified CAN message is received on the specified CAN
port. With the and condition conditions for a specified
CAN data byte can be set.
CAN message timeout With CAN message timeout it is possible to monitor, if a
port transmits a certain message within a defined time.
If Timeout after is set to start delay expired, the delay
time from the power on until the start of the timeout
timer has to be defined.
Cyclic timer expired With Cyclic Timer expired it is possible to set a cycle
time, so that a defined action is executed when the set
cycle time is expired.
CAN busoff detected –
CAN error status Error of CAN controller, controller is in error passive
passive state (controller cannot send error frames)
CAN error status No error, controller is in error active state (controller
active can send error frames if needed), event is only reported
if CAN controller was in CAN Error Status Passive
CAN data overrun –
detected
CAN no The event CAN no communication is triggered, if there
communication is no CAN communication for 10 seconds on the
defined port (observe Start-up delay time configured in
Communication Error Severity, p.
Power on Power on of the device
Soft reset detected A soft reset is done when a new configuration is loaded
via the CAN-Gateway Configurator
4.02.0332.20001 Version 1.7
CAN-Gateway Configurator V6 for CAN@net NT and CANbridge NT
Further settings
CAN Port: port to receive the message
CAN message format: standard or
extended
CAN identifier: identifier of the
message to be received
AND <condition>:
Select condition: Data Byte
CAN Data Byte: data0 to data7
Arithmetic operator: equal (==),
unequal (!=), higher (>), lower (<),
bitwise and (&)
Compare value: value to compare the
specified data byte with (hexadecimal
or decimal)
CAN Port: port to transmit the
message
CAN message format: standard or
extended
CAN identifier: identifier of the
message to be transmitted
Timeout after: first message reception
starts the timer after the first
reception of the message. start delay
expired starts the timer after Power
on when the configured delay time is
expired.
Timeout start delay time: after power
on of the device in milliseconds, only
if Timeout after is set to start delay
expired
Timeout value: in milliseconds
Cycle time: in milliseconds (>= 10 ms)
Start delay time: after power on of
the device
CAN Port
CAN Port
CAN Port
CAN Port
CAN Port
20).
–
–
