CAN-Gateway Configurator V6 for CAN@net NT and CANbridge NT
Configuration
1. Select Mapping Table in the configuration tree.
• Form to specify the mapping table appears on the right side.
NOTE
If new mapping tables are loaded, already available mapping table entries are deleted.
2. To load an existing mapping table, click button Import.
• Window Select a File is opened.
or
3. Configure the routing for each group of CAN messages.
IMPORTANT
If hexadecimal values are used, they must begin with 0x.
Example: 0x55
4. To select a row left-click on the left number column.
5. To edit the cell content, click on the cell.
• Drop-down list is opened.
6. To add a row, right-click on the left number column and select Insert new cells.
To verify a configured row:
1. Open menu View and select Show status window.
• Status window is displayed in the CAN-Gateway Configurator.
2. Click button Verify.
• Status, errors and warnings are showed in the status window.
3. To save the configured mapping table as template, click button Export.
Page 34 of 56
Mapping Table
4.02.0332.20001 Version 1.7
